In the Filtreau UV-C Pond Basic, are a UV-C radiation with a wavelength of 253.7 nm generated by a powerful Philips germicide UV-C ( Ultra-Violet ) lamp ensuring an efficient disinfection on algae and bacteria (including Legionella bacteria).
Working :
The water are led through the Filtreau UV-C Pond Basic purifier by a pump where the UV-C radiation neutralizes bacteria, viruses and other primitive organisms and stops them from multiplying. This Filtreau UVC Pond Basic system ensure you that your water will be safe, fresh and clean in an efficient and environmentally-friendly manner without using chemicals..
Improvements to earlier systems :
The robust 2mm thick tubes of the Filtreau UVC purifier are bigger than most common UV systems on the market and have a diameter of 90mm what have the benefits that the water flow speed are reduced with 25% inside the inox stainless steel 304L UV radiation reactor what give the special high output UV lamp more ultraviolet radiation time on the passing water then other systems with the same wattage lamp.
Extra UV reflection :
The Filtreau UVC Pond Basic systems have an inox 304L Stainless Steel UV reactor and are build for fishponds and non chemical swimming pools, the pollist interior ensures the reflection of the UV-C radiation and increasing the efficiency up to 35% and comes complete with UV-C lamp and reduce connectors.
Application :
Because of the size of almost one meter lang the Filtreau UVC Pond Basic are this the perfect purifier for private people and professionals with high demands for disinfection of water and / or control of algae in ponds and swimming ponds where no chlorine or chemicals are used.
Simple instalation:
The unit comes for a minimum pressure loss with a 63 mm inlet / outlet connection and because of the bottom outlet are this Filteau UVC Titan unit easy to install and will be fully supplied with a manual , electronic ballast , Philips high-frequency UV-C lamp and mounting brackets
E.U. Regulatuions :
All Filtreau UVC system meet the new EU regulation and have a safety switch witch make sure the lamp only burn when the lamp are safe in the housing what guarantees optimal safety for the user against UV radiation contact to eye,s and skin during maintenance or change lamps.
Advantages of UV-C treatment:
- Ensures fresh, clean and clear water
- Disinfects water efficiently and safely
- Protects your fish and users from germs
- Keeps the formation of mould, bacteria and algae under control
- More environmentally-friendly than traditional clear water treatment methods
Advantages of the Filtreau UVC Pond Basic :
- Broad diameter 90 mm housing for optimal UV-C exposure
- Up to 35% more UV-C yield as a result of reflection
- Robust 2mm thick Inox 304L stainless Steel housing
- Has a lamp safety switch to prevent UV eye / skin contact.
- Estimated lifespan uv lamp 8000 hours
- 360° flexibility connection possibilities for easy installation and maintenance
- Longer UV exposure time for better disinfection
- Estimated lifespan Philips uv lamp 8000 hours
- Made in Holland
- 2-year guarantee with respect to manufacturing faults
- Earthed
.
Technical specifications | Filtreau Basic 15000 | Filtreau Basic 40000 | Filtreau Basic 80000 |
Max water content | 15.000 L | 40.000 L | 80.000 L |
Lamp | 16 Watt | 40 Watt | 75 Watt |
UV-C (W) | 3,9 Watt | 15 Watt | 25 Watt |
Max. flow through | 8000 L/h | 15000 L/h | 20000 L/h |
Max. pressure | 3 bar | 3 bar | 3 bar |
Connection size | Ø63 mm | Ø63 mm | Ø63 mm |
Length of the device | 56 cm | 100 cm | 100 cm |
